Manufacturer Part: | EMT ID: |
V-2026NC
|
6343
|
- Capacity at 0° Angle, 0° Blade Cant: 20” x 26.4”
- Capacity at 0° Angle, 5° Blade Cant: 20” x 24”
- Blade Motor: 7.5 HP
- Workbed Height: 39.4"
Description
Cosen offers a full line of vertical tilt-frame band saws in both semi-automatic and fully automatic styles, and offer machines in a variety of cutting capacities. All of Cosen's tilt-frame saws are built on a heavy duty saw frame and are designed to help reduce vibration during the cut and improve cutting performance. Each saw comes with the capability of cutting angles between 90° (straight cut) and 60° in both directions. All saws in the Tilt-Frame series also come standard with an automatic angle adjust built into the HMI to help make the cutting process simpler. Cosen's Vertical Til-Frame saws are excellent options for any fabrication production shop looking to make a transition into the vertical saw market.
Features
- Hydraulic tilt-frame head allows miter cutting from 0 degrees to plus/minus 60 degrees
- Adjustable head cant from 0 to 5 degrees
- Gearbox designed to accept high lateral pressure (no thermal distortion)
- Inverter blade drive system which allows infinitely variable blade speeds
- 5.7” HMI touchscreen
- Adjustable flood coolant system
- Motor driven, synchronized wire blade brush
- Carbide blade guides and bearings provide additional blade support
- Rigid cast-iron guide arm
- Hydraulic blade tensioning device
- Precision feed pressure and feed rate dual valve system for optimal cutting performance
Specifications
- Capacity:
- 0° Angle
- 0° Blade Cant: 20” x 26.4”
- 5° Blade Cant: 20” x 24”
- 45° Left Angle
- 0° Blade Cant: 20” x 18.3”
- 5° Blade Cant: 20” x 16.7”
- 60° Left Angle
- 0° Blade Cant: 20” x 12.8”
- 5° Blade Cant: 20” x 11.8”
- 45° Right Angle
- 0° Blade Cant: 20” x 17.1”
- 5° Blade Cant: 20” x 15.7”
- 60° Right Angle
- 0° Blade Cant: 20” x 10.4”
- 5° Blade Cant: 20” x 10”
- 0° Angle
- Blade Speed: 50 - 330 FPM
- Blade Size (LxWxT): 17' 1.9" x 1.25" x .042
- Blade Motor: 7.5 HP
- Coolant Motor: 1/4 HP
- Workbed Height: 39.4"
- Weight: 4,520 lbs
- Floorspace (LxWxH): 102" x 98.4" 98.4"
Manufacturer | |
SKU |
V-2026NC
|
Shipping Method |
Flatbed
|
Weight |
4,650 lb
|
Dimensions |
120 × 90 × 94 in
|
Warranty |
1 Year
|
