*Image may display optional items not included with purchase.
You might also be interested in...
Manufacturer Part: | EMT ID: |
181359
|
15253
|
- Table load capacity: 330 lbs.
- Number of T-slots: 3 positions
- T-slots, width: 0.6”
- T-slots, spacing: 3.9”
Description
This model is very popular with customers who are looking for a quick, inexpensive solution for smaller workshops or who want to convert from conventional to CNC machining.
Features
- Powerful BT 40 spindle with speeds up to 8,000 rpm
- Solid cast-iron machine frame with extra low center of gravity and small footprint
- Siemens 808D control and Siemens drives ensure maximum process reliability and efficient programming
Machine Design
- Solid Y-shaped cast-iron machine body integrates many years of experience and state-of-the-art technology
- All axes move on premium, fully enclosed linear guideways and precision ball screws for high accuracy and low friction
- Solid machine table features 3 slots and a load capacity of 150 kg
- The Z axis drive is supported by a counter-weight with guide rollers
- Electronic hand-wheel simplifies machine set-up
- The automatic central lubrication system ensures proper lubrication of all lube points
Spindle
- Spindle runs on multiple bearings to ensure excellent absorption and dissipation of forces during machining
- The premium spindle unit features a large tool mount and includes a spindle oil cooler - a great advantage in continuous operations
Tool Changer
- Robust 12-station tool changer with tool changing time of 7 seconds
- For a max. workpiece weight of 3 kg
Standard Equipment
- Siemens 808D Advance control
- 12-station automatic tool changer
- Electronic hand-wheel
- Coolant system
- Operational health status indicator
- Automatic central lubrication
- Enclosure
- Level pads and bolts
- Work lamp
- Compressed air gun
- Operating tools
- Operator instructions
Controls & Software
- SINUMERIK 808D ADVANCE -- the perfect solution for modern standard machines
- CNC and drive communicate via a high-speed bus to ensure efficient positioning control plus high precision and optimum cutting performance
- This is topped by a guaranteed superior price/performance ratio
- This globally leading CNC technology provides high performance and power for the control of standard lathes
- In combination with a new generation of spindle and axis drives, the SINUMERIK 808D ADVANCE with 8.4" LCD provides an innovative ready-to-use digital CNC solution for modern standard machines
- Advantages - Digital solution provides higher precision:
- Increased overload capacity supports a faster acceleration and deceleration of machine tools
- Constant cutting speeds result in an increased surface quality of the workpiece
- Increased ruggedness:
- During heavy machining operations, an automatic spindle torque adjustment will help protect machining tools and spindle systems.
- The SINAMICS features a wide voltage range to prevent machine shut-downs during poor voltage supply conditions. This will significantly reduce machine down-times.
- Increased operator comfort:
- A fast Ethernet connection facilitates easy start-up and diagnostics of machine tools and simplifies NC program use
Specifications
- Working Area
- Table load capacity: 330 lbs.
- Number of T-slots: 3 positions
- T-slots, width: 0.6”
- T-slots, spacing: 3.9”
- Spindle nose-to-table surface distance: 4” - 23”
- Table dimensions: 24” x 12”
- Travels
- Travel X-axis: 15.7”
- Travel Y-axis: 9”
- Travel Z-axis: 18”
- Headstock
- Spindle mount: BT 40 null
- Spindle speed: 8000 rpm
- Feed
- Work feed X-axis: 0.039”/min - 393.7”/min
- Work feed Y-axis: 0.039”/min - 393.7”/min
- Work feed Z-axis: 0.039”/min - 393.7”/min
- Rapid feed X-axis: 472”/min
- Rapid feed Y-axis: 472”/min
- Rapid feed Z-axis: 394”/min
- Tool Head
- Number of tool stations: 12 positions
- Tool weight max.: 7 lbs.
- Tool-change time tool/tool: 7 sec
- Tool Ø: 2.16 (4.72)”
- Tool length (max.): 8”
- Accuracies
- Positioning accuracies: 0.0008”
- Repeatability: 0.00039”
- Drive Capacity
- Motor rating main drive: 5 Hp
- Total power consumption: 10 kVA
- Motor rating X-axis: 1 Hp
- Motor rating for Y-axis drive: 1 Hp
- Motor rating Z-axis: 1.34 Hp
- Measures and Weights
- Overall dimensions (length x width x height): 83” x 75” x 97”
- Weight: 4,840 lbs.
Options
- 270307 - E.T. Box LAN
- 270308 - E.T. Box WIFI
- 270309 - E.T. Box W4G
- 103920 – Shell End Milling Arbor Ø13 BT 40
- 103930 – Shell End Milling Arbor Ø16 BT 40
- 103922 – Shell End Milling Arbor Ø22 BT 40
- 103924 – Shell End Milling Arbor Ø27 BT 40
- 103926 – Shell End Milling Arbor Ø32 BT 40
- 103928 – Shell End Milling Arbor Ø40 BT 40
- 106821 – Milling Chuck WELDON BT 40 / Ø 0.24 in
- 106822 – Milling Chuck WELDON BT 40 / Ø 0.3 in
- 106823 – Milling Chuck WELDON BT 40 / Ø 0.4 in
- 106824 – Milling Chuck WELDON BT 40 / Ø 0.47 in
- 106825 – Milling Chuck WELDON BT 40 / Ø 0.63 in
- 106826 – Milling Chuck WELDON BT 40 / Ø 0.78 in
- 106828 – Milling Chuck WELDON BT 40 / Ø 1.26 in
- 103742 – Adapter BT 40 / MT 2
- 103744 – Adapter BT 40 / MT 3
- 103746 – Adapter BT 40 / MT 4
- 104202 – Collet Chuck BT40-ER32
- 104206 – Collet Chuck MAS BT40-ER40-80
- 106052 – ER 32 Collet Set 6 pcs.
- 104785 – Drill Chuck Arbors BT 40 / B 16
- 104786 – Drill Chuck Arbors BT 40 / B 18
- 104765 – Keyless Drill Chuck 0.04-0.5 in B 16
- 104770 – Keyless Drill Chuck 0.12-0.63 in B 18
- 108930 – Assembly Stand MAS-BT40, SK40
- 104930 – HNCS 100V
- 105295 – Clamping Tool Set De Luxe 14/M12
Manufacturer | |
SKU |
181359
|
Shipping Method |
Flatbed
|
Weight |
5,040 lb
|
Dimensions |
88 × 80 × 102 in
|
Country of Origin |
China
|
