LulzBot Fresh Certified Syringe Pump Extruder Bio 3D Printer KT-PR0054NA
Manufacturer Part: | EMT ID: |
KT-PR0054NA
|
16800
|
- Technology: Fluid Deposition Fabrication (FDF)
- Tool Head: Syringe Pump Extruder
- Min. Layer Resolution: 0.05 mm (50 μm)
- Print Volume Dimensions: 6.30in x 6.30in x 3.5in
Description
The LulzBot Bio is a FRESH™ certified bioprinter ready to print bioinks, unmodified collagen, and other soft materials for pharmaceutical/cosmetic testing, tissue engineering, regenerative medicine, and so much more.
- Ready-to-print bioinks, unmodified collagen, and other soft materials
- Easy, high-detail results
- Configurable for fast and ever-changing innovation
Real Materials, Real Innovation
The LulzBot Bio is optimized for Freeform Reversible Embedding of Suspended Hydrogels (FRESH™) printing. Out of the box, users can print real, unmodified collagen, alginate, and other soft materials. This brings researchers closer than ever before to recreating human physiology for in vitro testing and regenerative medicine. Combined with an ultra-precise syringe pump extruder, the Bio is ready for a wide variety of bioprinting applications, from creating multi-scale vasculature to fully functional heart tissue and more.
Heated Bed
The LulzBot Bio’s variable temperature heated bed allows full control of environmental conditions during printing, ensuring the integrity of the print from start to removal.
High-Detail Bioprinting
The syringe pump extruder design allows for precise control of material extrusion, enabling printing of high-detail objects in a wide range of materials with varying viscosities.
Material Options
The LulzBot Bio features an open materials system which includes ready-to-print profiles for alginate and unmodified collagen. With a configurable syringe pump system and extrusion settings, the Bio is easily adjustable for new materials and processes.
Designed for the Lab
The small footprint and large build volume easily fits within laminar flow cabinets or on lab countertops. The rugged design can easily be sterilized for printing cells using ethyl alcohol and UV lights.
Easy-To-Use Interface
The Bio features a 4.5" glove-friendly touch screen and SD card slot for easy operation without the need to be tethered to a computer.
Open Source, Open Possibilities
Innovation in research demands flexibility. the Bio's FRESH™ Certified and Open Hardware Design gives researchers the keys to innovate, allowing machine capabilities to be easily adjusted for new materials and processes. the Bio's adaptable configuration can be modified to extrude:
- Other components of the extracellular matrix (hyaluronic acid, fibrin)
- Photo-curable resins
- Thermosets
- Silicon and epoxies
- And more.....
With and easy-to-use, configurable platform, the only limit is that of the imagination.
Specifications
- Printing
- Print Technology: Fluid Deposition Fabrication (FRESH™ Certified)
- Print Volume Dimensions: 160mm x 160mm x 89mm* (6.30in x 6.30in x 3.5in*)
- Print Volume: 2,278.4cm³ (138.9in³)
- Ambient Operating Temperature: From 5°C to 40°C (41°F to 104°F)
- Operating Footprint: 76.2cm x 63.5cm x 53.3cm (30in x 25in x 21in)
- Maximum Travel Speed: 200 mm/sec
- Connectivity: USB Serial or SD Card
- Interface: 4.5" Glove-friendly touch-screen
- Included Tool Head: Syringe Pump Extruder (compatible with 2.5mL, 5mL, and 10mL)
- Provided Syringe: Hamilton 2.5 mL Gastight Syringe Model 1002 TLL, PTFE Luer Lock
- Needle Diameter: 50, 25 gauge and 50, 30 gauge dispensing needles included
- Print Surface: Heated Borosilicate Glass
- Maximum Print Bed Temperature: Up to 120°C (248°F)
- Print Bed Heat Up Time: 23°C to 60°C (73°F to 140°F) in 97 seconds
- Minimum Layer Resolution: 0.05mm (50 μm)
- Minimum Positive Feature Size: 0.08 mm (80 µm)**
- Calculated XYZ positional resolution: 10, 10, <5 micron
- Materials
- Supported Materials: FRESH Certified open material system with ready-to-print profiles for collagen and sodium alginate
- Additional Items Included
- Comprehensive Tool Kit
- Includes: Tool Kit Bag, 2.5 mL Gastight Glass Syringe, 25 gauge dispensing needles, 30 gauge dispensing needles, Hypodermic Leur Lock, Cole-Palmer Female Leur , Cole-Palmer Male Leur, 35mm Plastic Petri Dish, 50 mL KIMAX crystallizing dish, Celltreat Petri Dish, Spoon Scoopula, Specimen Cup w/ Lid, Transfer Pipette, Ball Hex Key Wrench Set, Power Cord, USB Cord, SD Card, Syringe Thumb Screws, Syringe Base and Clamps
- Comprehensive Documentation
- Includes: Quick Start Guide, Quality Assurance Record, and more.
- First 3D Print Material: Includes Sodium Alginate, LifeSupport Gel, and everything you need to complete your first print.
- Comprehensive Tool Kit
- Physical Dimensions
- Boxed Unit Weight: 12kg (26.5lbs)
- Unit Weight: 9kg (19.85lbs)
- Boxed Dimensions: 55.8cm x 43.2cm x 48.3cm (22in x 17in x 19in)
- Dimensions with Syringe Pump Extruder at Z max: 45.7cm x 33.9cm x 49.53cm (18in x 13in x 19.5in)
- Average Operating Dimensions: 76.2cm x 63.5cm x 53.3cm (30in x 25in x 21in)
- Software
- Operating System Compatibility: GNU/Linux, Mac, Windows
- Recommended Software: Cura LulzBot Edition Version 3.2 or newer
- Firmware: Marlin
- Supported File Types:.stl, .obj, .g, .gcode, .x3d, .3mf
- Electrical
- Power Requirements: 100VAC-240VAC, 50Hz-60Hz, 3.2A max
- Output: 24VDC
- Power Supply: Auto-switching MEAN WELL RSP-500-24
- Power Cable: IEC cord, C13 to region-specific connector
- Safety and Compliance
- Certifications: ETL/UL, CSA, FRESH, OSHWA
- Warranty: Includes one-year warranty and access to technical support five days a week. Optional one, two, or three-year extended warranties available.
- Country of Origin: Made in USA
Manufacturer | |
SKU |
KT-PR0054NA
|
UPC |
810234031233
|
Shipping Method |
Ground
|
Weight |
29 lb
|
Dimensions |
18 × 23 × 20 in
|
Country of Origin |
United States of America
|
Warranty |
1 Year
|
