Manufacturer Part: | EMT ID: |
2800-48-16
|
14085
|
- Bending Length: 48" w/ 49" of Clearance
- Max. 1-1/2" Lift of Beam Max.
- 125° Degree of Bend Max.
- Max Capacity: 16ga Mild Steel, 20ga Stainless, 12ga Aluminum
Description
The ULTIMATE Box & Pan Brake has a unique “3 Finger” design. This design incorporates moveable fingers on the bed and apron as well as the usual upper fingers. This design allows the operator to make bend combinations that were extremely difficult if not impossible before. The ULTIMATE Box & Pan Brake has wrenchless upper set back adjustments and is designed to bend 16 gauge mild steel the full width with the included apron angle fingers.
Includes:
- 1”, 2”, 3” (qty. 1), 6” (qty. 7) Upper Fingers
- 1”, 2”, 3”, 6” (qty. 1), 12” (qty. 3) Bed Fingers
- 1”, 2”, 3”, 6”, 12” & 24” Apron Angle Fingers
Features & Specifications
- Bending Length: 48" w/ 49" of Clearance
- Machine Height 26"
- 3-1/2" Depth of Box
- Max. 1-1/2" Lift of Beam Max.
- 125° Degree of Bend Max.
- 2" Down leg Max.
- Front to Rear Adjustment: 1"
- Max Capacity:
- 16ga (.062") Mild Steel
- 20ga (.0375") Stainless
- 12ga (.080") Aluminum
*Does NOT Include Stand, Stand Can Be Purchased Separately Part # 2800-400*
Manufacturer | |
SKU |
2800-48-16
|
Shipping Method |
LTL Freight
|
Weight |
585 lb
|
Dimensions |
75 × 35 × 36 in
|
Country of Origin |
United States of America
|
Warranty |
1 Year
|
