PurePressure 5 Ton Automated Pressure Control Pikes Peak Rosin Extraction Press V2 PPF005
Manufacturer Part: | EMT ID: |
PPF005
|
11023
|
- Press up to 20 grams of flower or 35 grams of kief or hash
- Premium 10" x 2.5" heat plate
- Save up to 30 pre-set recipes
- Automated Pressure Control
Description
The Pikes Peak Press was engineered to provide years and years of reliability while giving you the highest quality press on the market. You, the user, has complete control over heat plate temperatures, press time, operating pressure (digital readout), and actuating speed. The pneumatic cylinder requires no oiling or maintenance and through its unique design is able to achieve nearly 5 tons of force with only 120 PSI compressed air. These extremely high forces ensure that all of your rosin is extracted efficiently. All PurePressure products are manufactured in the USA and they guarantee unrivaled quality.
Automated Pressure Control
This feature replaces the Dual Pressure regulator system with a fully digital pressure control unit, thereby dramatically increasing material throughput and ease of use, even with the most difficult to press materials.
Features
- Unparalleled rosin press pressure control, all from from the Pressware™ screen - increase by as little as 1 PSI at a time or simply set the PSI to whatever you want
- The new "Warmup" features allows you to pause the position of your plates wherever you'd like so that you can pre-warm your bag, like a hydraulic rosin press
- Pick a bag size, a material type, and the system will do the rest for you with its professionally crafted rosin recipes that make it almost too easy
- Make your own recipes and set the pressure stages, the press will run hands-off whatever you set it to
- Premium 10" x 2.5" heat plate kit for the highest possible quality rosin production
- Press up to 20 grams of flower or 35 grams of kief or hash at a time with ease
- Features Pressware™ technology, which offers a full color LCD touch screen with custom software for even more control
- Save up to 30 pre-set recipes so once you dial in your settings you can repeat your results
- 5 tons of pressure output (9,876 lbf @ 120 PSI compressed air) from our custom fabricated, oil-less, maintenance-free pneumatic cylinder
- 2 year manufacturer's warranty on the pneumatic cylinder and frame; 1 year manufacturer's warranty on everything else
- Even heat distribution from 0°F - 300°F from in-house machined 100% aluminum plates, each with its own thermocouple
- Temperature accuracy to less than half of 1 degree Fahrenheit
- Ultra-durable powder coated construction
Specifications
- Weight: 120 lbs
- Overall Dimensions: Horizontal: 29.2” x 19.7” x 13.5” Vertical: 15.5” x 19.7” x 33.3”
- Power Requirement: 120/240VAC, 8A at startup / 2A continuous
- Compressed Air Requirements: PSI: 5 – 120 CFM: 2.1 or greater
- Pneumatic Cylinder Maximum Force Output: 9,876 lb @ 120 PSI
- Frame & Enclosure Metal: A36 Steel
- Heat Plates:
- Sizes: 10” x 2.5”
- Material: 6061 Aluminum
- Maximum Temperature: 300 °F
Options
- Complete Accessory Kit
- Air connection kit
Manufacturer | |
SKU |
PPF005
|
Shipping Method |
LTL Freight
|
Weight |
120 lb
|
Dimensions |
20 × 22 × 40 in
|
